Install the new jack plug socket that is delivered with the Flagship and plug the cable connected to the amplifier into the new cable socket.

Plug this cable into the FlagShip connector ( "yellow" and "green/without" colour markings).

Positive and negative poles that come from the pickup are to be removed from the jack plug socket by heating the solder connections.

Magnetic shield on the crimp connector is not marked with a dot.įor magnetically positive and negative poles, for example, the cable that was soldered to the jack plug socket can be used. Magnetic positive on the crimp connector is marked with a yellow dot. Please note: the piezo negative is not the general shield of the guitar. Piezo negative (black multi-connector of the Hannes bridge) to the crimp connector marked with a black dot. Piezo positive (red multi-connector of the Hannes bridge) to the crimp connector marked with a red dot. Make sure positive (red) and negative (black) are both on the correct side of the adapter (one side only), i.e. Plug the crimp connector into the adapter. Screw tight with the small screwdriver provided.

#Piezo bridge plus#

Next plug both the plus and the minus cables of the adapter into their corresponding crimp connector on the FlagShip preamp. Simply plug the crimp connector into the multi-connector/adapter. The plus and minus cable of each of the string saddles/piezo elements are bundled in the crimp connector. Connect the plus and minus cables of the magnetic pickup to the crimp connector (see below).Connect the positive and negative cables of the piezo bridge to the crimp connector (see below).Position and install the tone potentiometer.position the circuit board ‘away from the strings’ ) or 3-way rotary switch Position and install the 5-way lever (switch position 1 in the direction of the bridge, i.e.If necessary, drill suitable holes for the screws in advance. Attach the FlagShip unit with the two screws supplied or alternatively with the adhesive pad provided.Installation (if required please seek assistance from a guitar builder or technician)

Two screws and one adhesive pad for fixing the FlagShip unit into placeģ.Potentiometer Functions 3-way rotary switch.3-Way Rotary Switching Options in Mono- and in Stereo-Mode.Potentiometer Functions 5-way lever switch.5-Way Lever Switching Options in Mono- and Stereo-Mode.
